Description
The F-tone Networks FTQD-8H-DR8 is a transceiver module designed for 500m optical communication applications, and it is compliant to QSFPDD MSA, IEEE 802.3 protocol. The silicon photonics transceiver is based on a new state-of-the-art silicon photonics (SiPh) platform. It uses SiPh chips that integrate a number of active and passive optoelectronic components, 3D packaging technology and 7nm DSP chips. It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference. The module offers very high functionality and feature integration, accessible via a two-wire serial interface.

Features
● QSFPDD MSA and CMIS compliant
● 8x106.25Gbps(53.125GBd PAM4)electrical interface
● 8x106.25Gbps(53.125GBd PAM4)optics architecture
● Power consumption <18.5W
● Maximum link length of 500m G.652 SMF with KP-FEC
● MPO-16 receptacles
● Built-in digital diagnostic functions
● Operating case temperature 0°C to +70°C
● 3.3V power supply voltage
● RoHS compliant(lead free)

Applications
● 800GBASE-DR8
● Data center network
