Features
● Up to 106 Gbps data rate per channel by PAM4 modulation
● Support 16x100GAUI-1 electrical interface
● Integrated 850nm VCSEL array and PD array
● w/o DSP or CDR
● Up to 20m transmission with OM3 MMF
● Up to 50m transmission with OM4 MMF
● DDM function implemented
● Hot-pluggable OSFP-XD form factor
● Single +3.3V power supply

Applications
● Data centers and Cloud Networks

Standards
● Compliant to OSFP-XD MSA 1.1
● Compliant with CMIS 5.2
● 16x106. 25Gb/s electrical interface
● Maximum power consumption 8.5W
● Single +3.3V power supply
● Case temperature range: 0 ~ +70℃
● RoHS 2.0 complaint151617181920













北亿纤通 | F-tone Networks

企业邮箱：该邮件地址已受到反垃圾邮件插件保护。要显示它需要在浏览器中启用 JavaScript。
企业手机：19081343401
企业电话：028-85255257
企业传真：028-85977702

注：本产品有全国产化型号可选

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
